Container Energy Storage（Industrial）
These systems save costs by balancing peak and valley power consumption. With efficient conversion, deep power supply, seamless switching, real-time monitoring, and multi-level protection, they offer comprehensive power management and intelligent control. Featuring multiple working modes and rapid response, container energy storage systems provide optimal performance and flexibility.
TECHNICAL SPECIFICATION


Model20 Feet40 Feet
DC side DC
Rated voltage768V
Rated capacity1680Ah3920Ah
Rated energy1290kWh3010kWh
AC side AC
Rated power630kW1260kW
Maximum power693kW1386kW
Rated current /Max. current909A/1000A1818A/2000A
Rated voltage400V(3P4W+PE,3-phase 5 wire)
Frequency50Hz
Basic Parameters
IP protectionIP54
Temperature control Industrial air conditioner
Fire suppressionHeptafluoropropane fire extinguishing system
Temperature-15ºC ~ 50ºC
Relative Humidity≤95%,non-condensing
Allowable altitude4000m(over 2000, it will operate in derating
Dimensions (L*W*H)6058 x 2438 x 2896 mm12192 x 2438 x 2896 mm
WeightAbout 17TAbout 38T
CommunicationRS485, Ethernet,4G
AccessoriesConnecting cables, lighting, switch sockets, etc. in the cabinet
